| FAA Information Effective: | 2013-12-12 |
| Airport Identifier: | GUM |
| Airport Status: | Operational |
| Longitude/Latitude: | 144-47-49.6756E/13-29-02.2293N -144.797132/13.483953 (Estimated) |
| Elevation: | 305 ft / 92.96 m (Surveyed) |
| Land: | 1657 acres |
| From nearest city: | 3 nautical miles NE of Agana, GU |
| Location: | Guam County, GU |
| Magnetic Variation: | 02E (2000) |
| Ownership: | Publicly owned |
| Owner: | A.b. Won Pat Guam Int'l Arpt Author |
| Address: | P.o. Box 8770 Tamuning, GU 96931-1278 |
| Phone number: | 671-646-0300 |
| Manager: | Charles H. Ada Ii EXECUTIVE DIRECTOR: CHUCK H. ADA II - OPS MGR: ED MUNA. |
| Address: | P.o. Box 8770 Tamuning, GU 96931 |
| Phone number: | 671-646-0300 |
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | No |
| Control Tower: | Yes |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | Yes |
| Sectional chart: | Gnc 7 |
| Region: | AWP - Western-Pacific |
| Traffic Pattern Alt: | 1002 ft |
| Boundary ARTCC: | ZUA - Guam |
| Tie-in FSS: | HNL - Honolulu |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | GUM (NOTAM-d service avaliable) |
| Certification type/date: | I E S 04/1995 |
| Federal Agreements: | NGPSY |
| Fuel available: | 100LLA1 |
| Airframe Repair: | MINOR |
| Power Plant Repair: | MINOR |
| Bottled Oxygen: | HIGH |
| Bulk Oxygen: | HIGH/LOW |
| Dimension: | 12015 x 150 ft / 3662.2 x 45.7 m |
| Surface: | ASPH-CONC, Good Condition |
| Surface Treatment: | Saw-cut or plastic Grooved |
| Pavement Class: | 69 /F/B/X/U |
| Edge Lights: | High |
| Runway 06L | Runway 24R | |
|---|---|---|
| Longitude: | 144-46-53.1500E | 144-48-43.4674E |
| Latitude: | 13-28-39.8700N | 13-29-30.3051N |
| Elevation: | 234.00 ft | 305.00 ft |
| Alignment: | 65 | 127 |
| ILS Type: | ILS/DME | |
| Traffic Pattern: | Left | Right |
| Markings: | Precision instrument, Fair Condition | Precision instrument, Fair Condition |
| Crossing Height: | 73.00 ft | 75.00 ft |
| Displaced threshold: | 1000.00 ft | 0.00 ft |
| VASI: | 4-light PAPI on left side | 4-light PAPI on left side |
| Visual Glide Angle: | 3.00° | 3.00° |
| Approach lights: | MALSR | |
| Runway End Identifier: | No | No |
| Centerline Lights: | No | No |
| Touchdown Lights: | No | No |
| Obstruction: | 420 ft tower, 18000.0 ft from runway, 1500 ft right of centerline, 34:1 slope to clear | , 50:1 slope to clear |
| Decleard distances: | Take off run available 10015.00 ft Take off distance available 10015.00 ft Actual stop distance available 10015.00 ft Landing distance available 10015.00 ft | Take off run available 11015.00 ft Take off distance available 11015.00 ft Actual stop distance available 11015.00 ft Landing distance available 11015.00 ft |
| Dimension: | 10014 x 150 ft / 3052.3 x 45.7 m |
| Surface: | ASPH-CONC, Good Condition |
| Surface Treatment: | Saw-cut or plastic Grooved |
| Pavement Class: | 69 /F/B/X/U |
| Edge Lights: | Medium |
| Runway 06R | Runway 24L | |
|---|---|---|
| Longitude: | 144-47-05.3412E | 144-48-37.2900E |
| Latitude: | 13-28-37.7751N | 13-29-19.8247N |
| Elevation: | 231.00 ft | 293.00 ft |
| Alignment: | 65 | 127 |
| ILS Type: | ILS/DME | |
| Traffic Pattern: | Left | Right |
| Markings: | Precision instrument, Fair Condition | Precision instrument, Fair Condition |
| Crossing Height: | 76.00 ft | 75.00 ft |
| Displaced threshold: | 0.00 ft | 1004.00 ft |
| VASI: | 4-light PAPI on right side | pulsating/steady burning on left side |
| Visual Glide Angle: | 3.00° | 3.00° ANGLE 3.00 DEGREES SAT. COVERAGE RESTRICTED TO 4 DEGREES LEFT AND 6 DEGREES RIGHT OF C/L. |
| Approach lights: | MALSR | |
| Runway End Identifier: | No | |
| Centerline Lights: | No | |
| Touchdown Lights: | No | No |
| Obstruction: | 420 ft tower, 18000.0 ft from runway, 1500 ft right of centerline, 34:1 slope to clear | 220 ft hill, 6600.0 ft from runway, 1200 ft left of centerline, 29:1 slope to clear |
| Decleard distances: | Take off run available 10014.00 ft Take off distance available 10014.00 ft Actual stop distance available 10014.00 ft Landing distance available 10014.00 ft | Take off run available 10014.00 ft Take off distance available 10014.00 ft Actual stop distance available 10014.00 ft Landing distance available 9014.00 ft |
| <1000' OVRN S END & 450' OVRN N END RWY 6L-24R. |
| DEP VFR ACFT MAINT RY HDG TIL PAST DEP END OF RY AND REACHING 1000 FT AGL; RGT PAT 24L/R DO NOT EXCEED 1500 FT AGL IN TFC PAT. |
| RY 06L/24R IN USE FOR DEPARTURES ONLY, NO LANDINGS. |
| FOR PARKING INFORMATION ALL ACFT CTC RAMP CTL. ALL ACFT DEP TERMINAL PARKING CTC RAMP CTL FOR ENGINE START AND PUSHBACK. |
| TRANSIENT ACFT PROVIDE 24 HRS ADVANCE INFORMATION TO EXEC MGR GUAM INTL ARPT AUTHORITY; 1-671-642-4455 MON-FRI 0800-1700 OR FAX 1-671-646-8823. |
| EFFECTIVE RY GRADIENT RY 06L 0.46% UP NE; RY 24R 0.70% DOWN SW; RY 06R 0.80 % UP NE; RY 24L 0.52% DOWN SW. |
| LGTD TWR 780 FT 1.3 NM ENE OF RY 24L THLD . |
| RISING TERRAIN 75 FT FM RY 24L THLD 140 FT EAST OF CNTRLN EXTENDED +8 FT. |
